Features and Options

  • High efficacy, low glare, ideal compact fluorescent replacement
  • Modular design, multiple interchangeable downlight engines and trims
  • Multiple trim options covering wide range of cutouts,Ø145~260mm
  • Deepset facetted reflector for low glare illumination
  • IPART and VEU accepted
  • TRIDONIC DALI/DSI, 1-10V dimming on request

Technical Data

IP Rating
IP20 (IP54 optional)
IK Rating
IK05
Luminaire system wattage*
10W ~ 22W
Luminaire luminous flux*
1000lm ~ 2200lm
Luminaire efficacy (avg.)
100lm/W (@4000K)
Correlated colour temperature
4000K, other CCT on request
Colour rendering index
Ra≥82
Beam
80°
Service lifetime*
>60,000h L70/B10
